Fluke 289 Industrial Data Logging Multimeter with True RMS
Fluke 289 Industrial Data Logging Multimeter with True RMS - Image 2

Fluke 289 Industrial Data Logging Multimeter with True RMS

The Fluke 289 is an industrial grade, logging multimeter. Something you’d want to use when troubleshooting equipment over time. It’s big, bulky, and powerful.

Available as in-store or call-to-order ONLY

In stock

Original price was: $1,376.89.Current price is: $1,189.88. CAD
You save (%)

📞 Call to Order: (403) 232-6268
SKU: 169987 Categories: , , Tag:

Description

The Fluke 289 is an industrial grade, logging multimeter. Something you’d want to use when troubleshooting equipment over time. It’s big, bulky, and powerful.

Features

  • True Industrial-grade RMS digital multimeter
  • TrendCapture displays logged session data for easy pinpointing of useful data
  • “Zoom” feature on trend gives the ability for deep analysis of TrendCapture data
  • Selectable ac filter mode for steader readings of noisy signals
  • Adjustable set points for recording & holding data via a percentage change parameter
  • Large 50,000 count, 1/4″ VGA dot matrix display featuring a white backlight
  • Logging function with expanded memory for unattended monitoring of signals over time.
  • Using on-board TrendCapture users can graphically review logged readings without needing a PC. Store up to 15,000 recorded events.
  • Save multiple logging sessions before requiring PC download
  • Two terminal 50 ohm range with 1 milliohm resolution, 10 mA source current, which is ideal for contactors & motor winding resistance measurements
  • Simultaneous low-Pass filter for voltage and frequency measurements – ideal for noisy signals
  • Lo-Z Volts mode offers low impedance voltage function to eliminate ghost voltage measurements
  • “i” onscreen information button describes function details
  • Real-time clock for automatic logfile time stamping
  • Relative mode to compensate for test lead resistance in low resistance and capacitance measurements
  • True-RMS AC voltage and current for accurate measurements on non linear signals
  • Measure up to 10A (20A for 30 second surges)
  • 1nF to 100,000uF capacitance range
  • Peak capture to record transients as fast as 250 µs
Fluke 289
True RMS Industrial Logging Multimeter — Specifications

DC Volts
Parameter Value
Range / Resolution 50.000 to 500.00mV
5.0000 to 50.000V
500.00 to 1000.0V
Basic Accuracy 0.00025

AC Volts
Parameter Value
Range / Resolution 50.000 to 500.00mV
5.0000 to 50.000V
500.00 to 1000.0V
Basic Accuracy 0.4% (True RMS)

DC Current
Parameter Value
Range / Resolution 500.00 to 5000.0µA
50.000 to 400.00mA
5.0000 to 10.000A
Basic Accuracy 0.06%

AC Current
Parameter Value
Range / Resolution 500.00 to 5000.0µA
50.000 to 400.00mA
5.0000 to 10.000A
Basic Accuracy 0.61% (True RMS)

Temperature (Excluding Probe)
Parameter Value
Range / Resolution -200 to 1350°C
Basic Accuracy 1.0%

Resistance
Parameter Value
Range / Resolution 50.000 to 500.00 Ω
5.0000 to 50.000 kΩ
500.00 kΩ to 5.0000 MΩ
50.00 to 500.0 MΩ
Basic Accuracy 0.05%
Low Ohm Range / Resolution
(2-wire connection)		 50.000 Ω
Low Ohm Accuracy 0.15% + 20

Capacitance
Parameter Value
Range / Resolution 1.000 to 10.00nF
100.0nF to 1.000µF
10.00to 100.0µF
1000µF to 100000µF
Basic Accuracy 1.0%

Frequency
Parameter Value
Range / Resolution 99.999 to 999.99Hz
9.9999 to 999.99kHz
Basic Accuracy 0.005% + 5

Additional Functions / Features
Multiple On-Screen Displays Yes
True RMS AC Bandwidth 100 kHz
DBV/dBm Yes
DC mV Resolution 1 µV
Megohm Range Up to 500 MΩ
Conductance 50.00 nS
Continuity Beeper Yes
Battery / Fuse Access Battery / Fuse
Peak 250 µS
Elapsed Time Clock Yes
Time of Day Clock Yes
Min-Max-Avg Yes
Frequency Yes
Duty Cycle 0.01% to 99.99%
Pulse Width 0.025 ms, 0.25 ms, 2.5 ms, 1250.0 ms
Hold Yes
Isolated Optical Interface Yes
Auto / Touch Hold Yes
Reading Memory Yes
Log to PC Yes
Interval / Event Logging Yes
Logging Memory Up to 10,000 readings
Resistance Low Ohm 0.001 Ω to 50.000 Ω, 10 mA source
LoZ Yes
Low Pass Filter Yes

Environmental Specifications
Operating Temperature -20 to 55°C
Storage Temperature -40 to 60°C
Relative Humidity 0 to 90% (0 to 37°C)
0 to 65% (37 to 45°C)
0 to 45% (45 to 55°C)
Electromagnetic Compatibility EMC EN61326–1
Vibration Random vibration per MIL-PRF-28800F Class 2
Shock 3.3 ft (1m) drop per IEC/EN 61010–1 3rd Edition

Safety Specifications
Maximum Voltage Between Any Terminal and Earth Ground 1000 V
Agency Approvals CSA, UL, TÜV, CE

Mechanical & General Specifications
Dimensions (H × W × L) 222×102×60mm
Weight 1.92 lbs (870.9 g)
Battery Type 6 × AA Alkaline batteries, NEDA 15A IEC LR6
Battery Life 100 hours minimum, 200 hours in logging mode

Additional information

Weight 0.68889 kg
Dimensions 17.4 × 31.9 × 9.4 cm
Availability

In Store Only
Manufacturer

Manufacturer SKU289
SupplierFLUKE CANADA
